DH-SD4A216DB-HNY
Уличная мини-PTZ IP-видеокамера 2Мп; 1/2.8” CMOS; 16x моторизованный объектив 5~80мм; механический ИК-фильтр; WDR(120дБ); чувствительность 0.005лк@F1.6(цвет); сжатие: H.265+, H.265, H.264+, H.264, MJPEG; 3 потока до 2Мп@25к/с; видеоаналитика: автоматическое слежение, охрана периметра, SMD 3.0 (интеллектуальный детектор движения), детектор лиц; тревожные вх/вых: 2/1; аудиовх/вых: 1/1; MicroSD до 512Гбайт; защита: IP66; питание: 12В(DC), PoE+
Производитель: Dahua Technology
- Код:
- 00053925
- Базовая единица
- шт
54 790 руб.
2MP 16x WizSense NETWORK PTZ CAMERA
- 1/2.8" 2Megapixel STARVIS™ CMOS.
- 16x optical zoom.
- Starlight technology.
- Max. 25/30fps@2MP.
- IR distance up to 100 m.
- Auto-tracking 1.0.
- Perimeter protection.
- Face detection.
- SMD 3.0.
- IP66.
Технические характеристики:
| Camera | |
| Image Sensor | 1/2.8" CMOS |
| Pixel | 2MP |
| Max. Resolution | 1920 × 1080 |
| ROM | 128 MB |
| RAM | 512 MB |
| Electronic Shutter Speed | 1/1s~1/30000s |
| Scanning System | Progressive |
| Min. Illumination |
Color: 0.005 lux@F1.6 B/W: 0.0005 lux@F1.6 0 lux (IR on) |
| Illumination Distance | 100 m (328.08 ft) (IR) |
| Illuminator On/Off Control | Zoom Prio; Manual; Auto; Off |
| Illuminator Number | 6 (IR) |
| Lens | |
| Focal Length | 5 mm–80 mm |
| Max. Aperture | F1.6–F3.5 |
| Field of View |
H: 53.9°–4.6° V: 30.3°–2.6° D: 60°–5.3° |
| Optical Zoom | 16× |
| Focus Control | Auto; semi-auto; manual |
| Close Focus Distance | 0.1 m–0.5 m (0.33 ft–1.64 ft) |
| Iris Control | Fixed |
|
DORI Distance Detect Observe Recognize Identify |
1,103.4 m (3,620.08 ft) 435.9 m (1,430.12 ft) 220.7 m (724.08 ft) 110.3 m (361.88 ft) |
| PTZ | |
| Pan/Tilt Range |
Pan: 0° to 360° endless Tilt: –5° to +90°, auto flip 180° |
| Manual Control Speed |
Pan: 0.1°/s–240°/s Tilt: 0.1°/s–160°/s |
| Preset Speed | Pan: 240°/s; Tilt: 160°/s |
| Preset | 300 |
| Tour | 8 (up to 32 presets per tour) |
| Pattern | 5 |
| Scan | 5 |
| Power-off Memory | Yes |
| Idle Motion | Pattern;Preset;Scan;Tour |
| PTZ Protocol | DH-SD |
| Intelligence | |
| IVS (Perimeter Protection) | Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification; linkage tracking |
| Face Detection | Supports face detection, face track box, capturing pictures, face enhancement; Supports face cutout: Face, one-inch photo. Capturing strategies include real-time capturing and quality first |
| Auto Tracking | Human tracking based on Auto Tracking 1.0 technology |
| SMD | SMD 3.0 |
| Auto Patrol | It triggers the IVS rule when a target is detected and makes the camera link with the PTZ to rotate to the position of the target and patrol based on its presets |
| Video | |
| Video Compression | H.264H; H.264B; Smart H.265+; H.264; H.265; MJPEG (Sub Stream); Smart H.264+ |
| Streaming Capability | 3 streams |
| Resolution | 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Video Frame Rate |
Main stream: 1080p/1.3M/720p @(1–25/30 fps) Sub stream 1: D1/VGA/CIF@ (1–25/30 fps) Sub stream 2: 1080p/1.3M/720p @(1–25/30 fps) |
| Bit Rate Control | CBR/VBR |
| Video Bit Rate |
H264: 64 kbps–8192 kbps H265:25 kbps–6400 kbps |
| Day/Night | Auto (ICR)/Color/B/W |
| BLC | Yes |
| WDR | 120 dB |
| HLC | Yes |
| White Balance | Auto; indoor; outdoor; ATW; manual; sodium lamp; natural light; street lamp |
| Gain Control | Auto; manual |
| Noise Reduction | 2D NR; 3D NR |
| Motion Detection | Yes |
| Region of Interest (RoI) | Yes |
| Image Stabilization | Electronic (EIS) |
| Defog | Electronic |
| Digital Zoom | 16× |
| Image Rotation | 180° |
| Privacy Masking | Up to 24 areas can be set, with up to 8 areas in the same view |
| S/N Ratio | ≥ 55 dB |
| Audio | |
| Audio Compression | G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; PCM |
| Network | |
| Network Port | RJ-45 (10/100 Base-T) |
| Network Protocol | FTP;RTMP;IPv6;Bonjour;IPv4;DNS;RTCP;PPPoE;NTP;RTP;802.1x;HTTPS;SNMP;TCP/IP;DDNS;UPnP;NFS;ICMP;UDP;IGMP;SMB;HTTP;SSL;DHCP;SMTP;SNMPv1/v2c/v3(MIB-2);Qos;RTSP;ARP |
| Interoperability | CGI;SDK;ONVIF (Profile S&G&T);P2P |
| Streaming Method | Unicast/Multicast |
| User/Host | 20 (total bandwidth: 64 M) |
| Storage | Micro SD card (512 GB); FTP/SFTP; NAS |
| Browser |
IE 9 and later versions Chrome 41 and later versions Firefox 50 and later versions iOS 10 and later versions |
| Management Software | DSS;DSS Pro |
| Mobile Client | iOS;Android |
| Certification | |
| Certifications |
CE: EN55032/EN55024/EN50130-4 FCC: Part15 subpartB, ANSI C63.4-2014 UL: UL62368-1 |
| Port | |
| Audio Input | 1 channel (LINE IN, bare wire) |
| Audio Output | 1 channel (LINE OUT,bare wire) |
| Alarm Linkage | Capture; preset; tour; pattern; recordings on SD card; alarm digital input; send email; audio |
| Alarm Event | Motion/Tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection; |
| Alarm I/O | 2/1 |
| Audio I/O | 1/1 |
| Power | |
| Power Supply |
12 VDC/2 A ± 10% (included) PoE+ (802.3at) |
| Power Consumption |
Basic: 10 W Max.: 19 W (illuminator on + fan on + PTZ) |
| Environment | |
| Operating Temperature | –40 °C to +65 °C (–40 °F to +149 °F) |
| Operating Humidity | ≤ 95% |
| Protection | IP66, TVS 6000 V lightning proof; surge protection; voltage transient protection |
| Structure | |
| Product Dimensions | 170.4 mm × Φ171.1 mm (6.71" × Φ6.74") |
| Net Weight | 2.5 kg (5.51 lb) |
| Gross Weight | 3.2 kg (7.05 lb) |
